The Viola–Jones object detection framework is a machine learning object detection framework proposed in 2001 by Paul Viola and Michael Jones. It was motivated primarily by the problem of face detection, although it can be adapted to the detection of other object classes. In short, it consists of a sequence of classifiers. Each classifier is a single perceptron with several binary masks (Haar features). To detect faces in an image, a sliding window is computed over the image. For each image, the classifiers are applied. If at any point, a classifier outputs "no face detected", then the window is considered to contain no face. Otherwise, if all classifiers output "face detected", then the window is considered to contain a face. The algorithm is efficient for its time, able to detect faces in 384 by 288 pixel images at 15 frames per second on a conventional 700 MHz Intel Pentium III. It is also robust, achieving high precision and recall. While it has lower accuracy than more modern methods such as convolutional neural network, its efficiency and compact size (only around 50k parameters, compared to millions of parameters for typical CNN like DeepFace) means it is still used in cases with limited computational power. For example, in the original paper, they reported that this face detector could run on the Compaq iPAQ at 2 fps (this device has a low power StrongARM without floating point hardware). == Problem description == Face detection is a binary classification problem combined with a localization problem: given a picture, decide whether it contains faces, and construct bounding boxes for the faces. To make the task more manageable, the Viola–Jones algorithm only detects full view (no occlusion), frontal (no head-turning), upright (no rotation), well-lit, full-sized (occupying most of the frame) faces in fixed-resolution images. The restrictions are not as severe as they appear, as one can normalize the picture to bring it closer to the requirements for Viola-Jones. any image can be scaled to a fixed resolution for a general picture with a face of unknown size and orientation, one can perform blob detection to discover potential faces, then scale and rotate them into the upright, full-sized position. the brightness of the image can be corrected by white balancing. the bounding boxes can be found by sliding a window across the entire picture, and marking down every window that contains a face. This would generally detect the same face multiple times, for which duplication removal methods, such as non-maximal suppression, can be used. The "frontal" requirement is non-negotiable, as there is no simple transformation on the image that can turn a face from a side view to a frontal view. However, one can train multiple Viola-Jones classifiers, one for each angle: one for frontal view, one for 3/4 view, one for profile view, a few more for the angles in-between them. Then one can at run time execute all these classifiers in parallel to detect faces at different view angles. The "full-view" requirement is also non-negotiable, and cannot be simply dealt with by training more Viola-Jones classifiers, since there are too many possible ways to occlude a face. == Components of the framework == A full presentation of the algorithm is in. Consider an image I ( x , y ) {\displaystyle I(x,y)} of fixed resolution ( M , N ) {\displaystyle (M,N)} . Our task is to make a binary decision: whether it is a photo of a standardized face (frontal, well-lit, etc) or not. Viola–Jones is essentially a boosted feature learning algorithm, trained by running a modified AdaBoost algorithm on Haar feature classifiers to find a sequence of classifiers f 1 , f 2 , . . . , f k {\displaystyle f_{1},f_{2},...,f_{k}} . Haar feature classifiers are crude, but allows very fast computation, and the modified AdaBoost constructs a strong classifier out of many weak ones. At run time, a given image I {\displaystyle I} is tested on f 1 ( I ) , f 2 ( I ) , . . . f k ( I ) {\displaystyle f_{1}(I),f_{2}(I),...f_{k}(I)} sequentially. If at any point, f i ( I ) = 0 {\displaystyle f_{i}(I)=0} , the algorithm immediately returns "no face detected". If all classifiers return 1, then the algorithm returns "face detected". For this reason, the Viola-Jones classifier is also called "Haar cascade classifier". === Haar feature classifiers === Consider a perceptron f w , b {\displaystyle f_{w,b}} defined by two variables w ( x , y ) , b {\displaystyle w(x,y),b} . It takes in an image I ( x , y ) {\displaystyle I(x,y)} of fixed resolution, and returns f w , b ( I ) = { 1 , if ∑ x , y w ( x , y ) I ( x , y ) + b > 0 0 , else {\displaystyle f_{w,b}(I)={\begin{cases}1,\quad {\text{if }}\sum _{x,y}w(x,y)I(x,y)+b>0\\0,\quad {\text{else}}\end{cases}}} A Haar feature classifier is a perceptron f w , b {\displaystyle f_{w,b}} with a very special kind of w {\displaystyle w} that makes it extremely cheap to calculate. Namely, if we write out the matrix w ( x , y ) {\displaystyle w(x,y)} , we find that it takes only three possible values { + 1 , − 1 , 0 } {\displaystyle \{+1,-1,0\}} , and if we color the matrix with white on + 1 {\displaystyle +1} , black on − 1 {\displaystyle -1} , and transparent on 0 {\displaystyle 0} , the matrix is in one of the 5 possible patterns shown on the right. Each pattern must also be symmetric to x-reflection and y-reflection (ignoring the color change), so for example, for the horizontal white-black feature, the two rectangles must be of the same width. For the vertical white-black-white feature, the white rectangles must be of the same height, but there is no restriction on the black rectangle's height. ==== Rationale for Haar features ==== The Haar features used in the Viola-Jones algorithm are a subset of the more general Haar basis functions, which have been used previously in the realm of image-based object detection. While crude compared to alternatives such as steerable filters, Haar features are sufficiently complex to match features of typical human faces. For example: The eye region is darker than the upper-cheeks. The nose bridge region is brighter than the eyes. Composition of properties forming matchable facial features: Location and size: eyes, mouth, bridge of nose Value: oriented gradients of pixel intensities Further, the design of Haar features allows for efficient computation of f w , b ( I ) {\displaystyle f_{w,b}(I)} using only constant number of additions and subtractions, regardless of the size of the rectangular features, using the summed-area table. === Learning and using a Viola–Jones classifier === Choose a resolution ( M , N ) {\displaystyle (M,N)} for the images to be classified. In the original paper, they recommended ( M , N ) = ( 24 , 24 ) {\displaystyle (M,N)=(24,24)} . ==== Learning ==== Collect a training set, with some containing faces, and others not containing faces. Perform a certain modified AdaBoost training on the set of all Haar feature classifiers of dimension ( M , N ) {\displaystyle (M,N)} , until a desired level of precision and recall is reached. The modified AdaBoost algorithm would output a sequence of Haar feature classifiers f 1 , f 2 , . . . , f k {\displaystyle f_{1},f_{2},...,f_{k}} . The details of the modified AdaBoost algorithm is detailed below. ==== Using ==== To use a Viola-Jones classifier with f 1 , f 2 , . . . , f k {\displaystyle f_{1},f_{2},...,f_{k}} on an image I {\displaystyle I} , compute f 1 ( I ) , f 2 ( I ) , . . . f k ( I ) {\displaystyle f_{1}(I),f_{2}(I),...f_{k}(I)} sequentially. If at any point, f i ( I ) = 0 {\displaystyle f_{i}(I)=0} , the algorithm immediately returns "no face detected". If all classifiers return 1, then the algorithm returns "face detected". === Learning algorithm === The speed with which features may be evaluated does not adequately compensate for their number, however. For example, in a standard 24x24 pixel sub-window, there are a total of M = 162336 possible features, and it would be prohibitively expensive to evaluate them all when testing an image. Thus, the object detection framework employs a variant of the learning algorithm AdaBoost to both select the best features and to train classifiers that use them. This algorithm constructs a "strong" classifier as a linear combination of weighted simple “weak” classifiers. h ( x ) = sgn ( ∑ j = 1 M α j h j ( x ) ) {\displaystyle h(\mathbf {x} )=\operatorname {sgn} \left(\sum _{j=1}^{M}\alpha _{j}h_{j}(\mathbf {x} )\right)} Each weak classifier is a threshold function based on the feature f j {\displaystyle f_{j}} . h j ( x ) = { − s j if f j < θ j s j otherwise {\displaystyle h_{j}(\mathbf {x} )={\begin{cases}-s_{j}&{\text{if }}f_{j}<\theta _{j}\\s_{j}&{\text{otherwise}}\end{cases}}} The threshold value θ j {\displaystyle \theta _{j}} and the polarity s j ∈ ± 1 {\displaystyle s_{j}\in \pm 1} are determined in the training, as well as the coefficients α j {\displaystyle \alpha _{j}} . Here a simplified version of the lea
